Stacking Doors
Stacking Glass Door Installation in McKinney, TX
Stacking glass doors don’t just open wide. They disappear. Panels glide and stack completely behind one another, leaving a fully open wall with nothing in the way. Woodruff has been installing the kind of work that lasts since 1982.
Why Choose Woodruff Windows
A stacking door system is only as good as the pocket it stacks into. We build that right.
Most stacking door problems trace back to a pocket that wasn’t built to spec. We build it right. Our in-house crews handle the full scope on every project, from structural framing to finished threshold, so nothing gets handed off and nothing gets guessed at. Homeowners across Craig Ranch, Adriatica, and Trinity Falls know the difference.
Stacking Pocket Framing & Finish
We build or verify the stacking pocket to the panel system’s exact specifications before installation begins. The panels need somewhere to go when they’re open, and that space needs to be right.
In-House Crews. Never Subcontracted.
Structural framing, door installation, and interior finish work are all performed by the same Woodruff crew. No handoffs, no gaps in accountability from start to finish.
Threshold, Trim & Full Cleanup
We finish the threshold, interior casing, and exterior trim to match your home’s existing profile. Then we test every panel through its full range of motion and clean up before we leave.
Explore Stacking Glass Door Installation
Discover what makes a stacking glass door system the most complete indoor-outdoor opening available for McKinney homes.
Panels that move, stack, and leave nothing behind.
Full-Width Clear Opening
When fully open, every panel has moved into the stacking pocket, leaving the entire wall width as clear, unobstructed passage. No fixed panel. No frame in the view. Just the opening.
Top-Hung or Bottom-Roll Systems
Top-hung systems suspend panels from the overhead track, keeping the floor clear of any rail and allowing a truly flush threshold. Bottom-roll systems use a floor track for larger or heavier panel configurations where additional support is needed.
Individual Panel Operation
Panels can be opened partially or fully, one at a time or all at once, giving you control over how much of the wall is open at any moment. Partially open for a breeze. Fully open for a gathering.
When closed, it has to seal like a wall
Cardinal LoĒ³-366 Low-E Glass
Triple-silver-coated Low-E glass blocks 95% of UV rays across every panel, keeping the full glass wall from becoming a solar heat liability during McKinney’s peak summer months.
Thermally Broken Aluminum Frames
A thermal break between the interior and exterior frame surfaces prevents the aluminum from conducting heat into the home, maintaining the panel’s insulating performance independently of the glass.
Compression Seal System
When the panels are closed and locked, compression seals engage along the full perimeter of the system, creating a weather-tight closure that performs like a fixed wall, not an assembled set of panels.
A system this open needs hardware this solid
Multi-Point Panel Locks
Each panel in the closed position engages a multi-point lock at the top and bottom of the frame, compressing the seal evenly and securing the full panel height against forced entry.
Shoot Bolt End Locks
Shoot bolt hardware at the top and bottom of the end panel anchors the fully closed system into the frame, locking the entire assembly in place rather than relying on a single latch point.
Flush-Pull & Recessed Handles
Flush-pull handles sit recessed into the panel face, allowing smooth one-hand operation without hardware that protrudes into the opening or catches on screens and furnishings during use.
Glass that performs across the full wall
Tempered Safety Glass
Tempered glass is standard on all stacking door panels by code. Given the volume of glass in a full stacking system, there is no other appropriate specification.
Low-Iron Ultra-Clear Glass
Across a full stacking wall, standard glass’s green tint becomes distinctly noticeable. Low-iron glass removes it entirely, giving you a neutral, true-color view of your outdoor space from every panel.
Acoustic Laminated Glass
For homes where outdoor noise is a factor when the system is closed, laminated acoustic glass rated up to STC 34 keeps the view without importing the sound from nearby roads, common areas, or neighboring properties.
BRANDS WE INSTALL
Systems engineered for full-wall performance.
We source stacking glass door systems from vetted manufacturer partners whose top-hung hardware, panel tolerances, and seal systems we’ve evaluated specifically for North Texas conditions. Stacking systems face more daily mechanical stress than any other door type, and the brands we specify are built to handle it. Every system carries a manufacturer’s limited lifetime warranty backed by our own installation guarantee.
STACKING GLASS DOOR SPECS & PERFORMANCE
A stacking glass door system covers more wall than any other door configuration. Here’s how our three installation tiers compare on the specs that matter most for McKinney homeowners.
|
Feature / Spec |
Good (Standard) |
Better (Premium) |
Best (Architectural) |
|---|---|---|---|
|
Glass Panes |
Double-Pane |
Dual-pane with enhanced coating |
Triple-Pane |
|
Low-E Glass |
Cardinal LoĒ²-272 |
Cardinal LoĒ³-366 |
Cardinal LoĒ³-366 + low-iron option |
|
Insulating Gas |
Argon |
Argon |
Krypton |
|
U-Factor* |
0.28–0.33 |
0.23–0.28 |
0.23–0.28 |
|
SHGC* |
0.23–0.27 |
0.20–0.24 |
0.17–0.21 |
|
Frame Material |
Aluminum |
Thermally broken aluminum |
Thermally broken aluminum or fiberglass |
|
Warranty |
Limited Lifetime |
Limited Lifetime (transferable) |
Limited Lifetime + extended glass |
*U-Factor and SHGC ranges represent typical NFRC-certified performance for the South-Central climate zone. Stacking system values vary by panel count, track type, and glass package. Ask your Woodruff consultant for system-specific NFRC data.
What a fully open stacking wall does to a home
Homeowners in Stonebridge Ranch and Painted Tree describe it the same way: the house feels like a different building. Rooms that were enclosed feel expansive. Outdoor spaces that were adjacent feel integrated. The home stops having a backyard and starts having an extension. Here’s the measurable side of that experience.
100% clear opening across the full wall width when fully stacked, with no fixed panel, no center post, and no frame interrupting the threshold between interior and exterior.
Full thermal closure when all panels are locked, with compression seals engaging across the entire system perimeter and Cardinal LoĒ³-366 Low-E glass maintaining consistent performance across every panel.
Complete flexibility between fully open, partially open, and fully closed, with individual panel operation that no other door system provides at this scale.
*Performance estimates based on NFRC-certified data and manufacturer specifications. Actual results vary by system size, panel count, orientation, and home construction. Ask your Woodruff consultant for site-specific recommendations.
Design
When the panels are open, the design of your outdoor space becomes the design of your room.
When the panels stack back, the covered patio, the pool, the yard in Tucker Hill or Craig Ranch becomes the room’s focal point. Panel profile, frame finish, and glass clarity all shape how that feels. We work through every visual detail during the consultation so the system looks like it was always part of the architecture.
Flexibility
Fully open, fully closed, or anywhere in between.
Open two panels for a morning breeze. Open the full wall for an evening gathering. Close everything and lock it when the weather turns. In McKinney’s climate, where ideal outdoor conditions shift week to week, that range of control is useful year-round.
Testimonials
What Our Customers Say
Hear directly from Dallas homeowners about their exceptional experience with Woodruff Windows.
Recognized for Excellence
Gallery
Stacking glass door Inspiration
Real installs. Real McKinney homes. See how stacking glass systems look once the panels are in and the wall is open.
HOW IT WORKS
The most complex door we install MADE SIMPLE FOR YOU.
Stacking glass door installations involve more planning than most. Here’s how we manage the scope from start to finish.
Step 1
Free In-Home Consultation & Pocket Assessment
We visit your home, assess the wall and the stacking pocket location, and walk through your system options: panel count, track type, glass package, and frame finish. Written quote before we leave. Most consultations run 60 to 90 minutes for stacking system projects.
Step 2
Custom Manufacturing & Scheduling
Your system is built to order for your exact opening and panel configuration. Lead time is typically five to eight weeks depending on system complexity. We confirm your installation schedule in advance.
Step 3
Full Installation & System Walkthrough
Our crew handles pocket framing, track installation, panel hanging, seals, threshold, trim, and cleanup in a coordinated visit. We test every panel through its full range of motion and walk you through the locking system before we leave.
TRANSPARENT PRICING
What stacking glass door installation costs in McKinney.
Stacking system pricing is driven by panel count, track type, and wall scope. The ranges below cover a standard three-panel top-hung system in a typical residential exterior wall, including pocket framing, track, panels, threshold, and interior and exterior trim.
Standard Stacking System
$6,000 – $10,000
- Three-panel top-hung configuration with Cardinal LoĒ²-272 Low-E glass and argon gas fill
- Aluminum frame with standard color options and surface threshold
- Multi-point panel locks and shoot bolt end hardware
- Limited lifetime warranty
Most Popular
Premium Stacking System
$10,000 – $18,000
- Three to four panels with Cardinal LoĒ³-366 glass and argon gas fill
- Thermally broken aluminum frame with expanded color and hardware options
- Flush or recessed threshold with upgraded flush-pull hardware
- Limited lifetime transferable warranty
Architectural Stacking System
$18,000+
- Four or more panels with triple-pane or low-iron glass and krypton gas fill
- Premium thermally broken aluminum or wood-clad frame with full finish library
- Recessed flush threshold with acoustic glass and custom pocket finish
- Limited lifetime warranty with extended glass breakage coverage
*Pricing represents typical installed cost for a three-panel top-hung stacking system in a standard residential exterior wall, including pocket framing, track, panels, threshold, interior and exterior trim, and cleanup. Larger systems, bottom-roll configurations, structural modifications, and custom finishes will be scoped and quoted individually. All quotes are free, written, and no-obligation.
LET’S TALK ABOUT YOUR PROJECT
Get your free quote. We’ll assess the wall and the pocket and tell you exactly what’s involved.
Stacking glass door projects start with understanding the wall, the pocket location, and what full opening actually means for your space. Tell us about your project and we’ll reach out within one business day to schedule your in-home consultation. Honest scope, transparent pricing, no pressure.
FAQ
Good questions. Here are the honest answers.
When every panel stacks back, the wall disappears. That’s the point.
Stacking glass doors are the most complete indoor-outdoor opening we install, and the most satisfying project to finish. The full opening has to be experienced to be understood. Family-owned since 1982. In-house crews. No subcontractors. No surprises.
